NF-CS Motorized Circuit Breaker MCCB Non Explosive 2 Poles

Basic Information
Place of Origin: CHINA
Brand Name: NBSe
Certification: CE,ISO9000
Model Number: NF-CS
Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Export Carton
Delivery Time: 10-20day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10,000pcs per month
Detail Information
Material: ABS, COPPER Poles Number: 3 Pole
Rated Frequency: 50/60Hz Standard: IEC60947-2
Type: Moulded Case,Magnetic Rated Voltage: AC230/440/660
Product Name: Mccb Moulded Case Circuit Breaker Breaking Capacity: 25~100KA
Installation: Fixed And Plug-in,Easy To Install
High Light:

Non explosive motorised mccb

,

2 poles motorised mccb

,

Non explosive motor rated circuit breaker


Product Description

NBSe NF-CS MCCB mold case circuit breaker, circuit breaker mccb

factory directly provide Nf cs 3phase 100a 150a mccb



The product shall be operated under the following environmental conditions:



● Non-explosive;

● Does not contain corrosive gases and vapors in concentrations destroying metals and insulation;

● Not rich conductive dust and vapors;

● Lack of direct exposure to ultraviolet radiation;

● Should not be significant shock or vibration.



Specifications

1) The products conforms to GB14048.2,IEC60497-2 standards.
2) Equipment with the protection devices.



 Application and range of application

The NF-CS series plastic outer covering type circuit breaker (hereafter refers to as circuit breaker), is this company uses the international advanced design, one of the techniques of manufacture development, development new circuit breakers. Its fixed isolation voltage is 690V, is suitable in exchanges 50Hz, fixed working voltage 400V and below.Rated current to 800A circuit as frequent changeover gum less frequent motor starter. The Circuit breaker with overload, short circuit protection device, and less voltage protection circuit and power equipment are not damaged.



Technical parameter of MCCB

Type
Number of poles

Rated current in(A)

Rated voltage Ue(V)

Short-circuit Interrupting capacity Icu/Ics(KA)
DC AC
250V 230V 400V 440V 500V
NF30-CS 2 3,5,10,15,20,25,30 AC400(380)
AC690(660)
DC250
- 5/2 5/2 - -
3
NF50-CS 2 5,10,15,20,30,40,50 - 5/2 5/2 2.5/1 2.5/1
3
NF60-CS 2 10,15,20,20,40,50,60 - 5/2 5/2 2.5/1 2.5/1
3
NF100-CS 2 50,60,75,100 - 25/10 18/10 10/7.5 7.5/5
3
NF250-CS 3 125,150,175,200,225,250 - 25/10 18/10 15/10 10/7.5
NF400-CS 3 250,300,350,400 - 35/25 25/18 25/18 15/10
NF630-CS 3 500,600,630 - 50/35 35/25 35/25 18/10







Our Services



(1) Warranty ( 24 months warranty )

1. The warranty starts from the delivery date from our factory;

2. During the warranty, any defective product will get repaired or replaced for free ;

3. It is beyond the warranty as the products breaked by the violence , the carelessness or repaired , altered without authorization.



(2) Lead Time

1. Sample orders will be delivered from our factory within 7 working days.

2. General orders will be delivered from our factory within 7-15 working days.

3. Bulk orders will be delivered from our factory within 25 working days at most



(3) Shippment

1. By EMS, DHL, FedEx, TNT, UPS or other express.

2. By our forwarding agent (by air or by sea).

3. By your own forwarding agent.

4. By domestic forwarding agents to any city in China
