|Standard:||EN/IEC60947-2||Tripping Type:||Thermal/magnetic Release|
|Protection:||Overload And Short Circuit||Usage:||Low Voltage,Automotive,Thermal|
1P Miniature Circuit Breakers,
10kA Miniature Circuit Breakers,
10kA single pole circuit breaker
NBSM9 Series Plug In Miniature Circuit Breakers , New Arrival
NBSe NBSM9 Series 1P 50A Plug-in type circuit breaker, Pin type circuit breakers
This NT circuit breaker safely cuts off power immediately if the circuit becomes overloaded (too many electrical appliances being used), or short circuited (a faulty appliance). Plug in circuit breakers are more reliable and have a faster response time then standard rewireable fuses. Once installed, they do not require any tools to be reset, simply switch back on once the fault has been fixed.
One-piece moulded case construction.
Hardened cradle for positive action under fault conditions.
Heavy duty line terminal and spring clip for quick loadcentre installation and cool coperation.
Silver tungsten alloy contacts.
Magnetic assembly for reliable short circuit protection.
Large gas port for venting short circuit gases safely into loadcentre gutter.
Calibrated one-piece bimetal for reliable thermal trip function.
|♦ Standard:Confirming to EN / IEC,NOM ANCE|
|♦ Breaking capacity:10kA|
|♦ Protection:Against overload and short circuit|
|♦ Rated current In:15,20,30,40,50,63A|
|♦ Rated voltage:|
|◊ 1pole 230/400V AC 50/60Hz|
|◊ Rated insulation voltage Ui: 500V|
|◊ Rated impulse withstand voltage Uimp: 6000V|
|◊ Energy limiting class: 3|
|♦ Ambient temperature:-5°C to +40°C pursuant to EN / IEC60947|
|◊ Thermal operating limit: (1.13-1.45) x In|
|◊ Magnetic operating: B: (3-5) x In,C: (5-10) x In,D: (10-20) x In|
|♦ Number of poles:1P,2P,3P, 4P|
|♦ Type of trip:Thermal / magnetic release|
|♦ Type of terminal:Lug type and Pin type|
|♦ Terminal capacity:|
|◊ 16mm² flexible or 25mm² rigid up to 25A ratings|
|◊ 25mm² flexible or 35mm² rigid for 32A to 63A ratings|
|♦ Protection degree:IP20|
|♦ Installation:DIN rail|
|♦ Width:18mm per pole|
What is the difference between Plug-in and Fixed Circuit Breaker ?
The plug-in version makes it possible to:
