| Place of Origin: | CHINA |
|---|---|
| Brand Name: | NBSE/OEM |
| Certification: | CE, ISO9000 |
| Model Number: | DDC BACO |
| Minimum Order Quantity: | 100pcs |
| Price: | Negotiable |
| Packaging Details: | Export Carton |
| Delivery Time: | 15-25days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 30,000pcs per month |
| Poles: | 1P+N, 3P+N | Rated Voltage: | 220V/440V |
|---|---|---|---|
| Leakage Operating: | 300mA, 500mA | Rated Current: | 5-90A Adjustable |
| Standard: | NFC61450, NFC62411 | Shell: | Fire-proof, ABS |
| Type: | Residual Protection Molded Case BACO | Application: | Household,Terminal Distribution,Electricity Distribution Room |
| High Light: | NFC61450 rcbo module,Fireproof RCBO module,NFC61450 single phase rcbo |
||
Electrical Circuit Breaker EDF Baco (500 mA Selective 4P 10/30 A) edf 69-30-066
1. Application
The DDC breaker is divided into 2 poles and 4 poles. It can be applied to the circuit breaker installed on the control panel of the primary equipment, and can also be applied to the control terminal of the shopping mall, base station and home power supply board.
Feature as below:
1)This product has a high level of safety protection.
2)Not affected by ambient temperature.
3)Multi-step adjustable of rated current.
4)Rated current digital display.
5)With anti-stealing function
Specification:
PG series adjustable residual current circuit breaker(gardy rccb,gardy elcb)is suitable for AC 50/60Hz,230/400V circuit,prevents from overloading,short-circuit etc.On the occasion of shock hazard or earth leakage,it will trip immediately.At the same time,the rated current of overload protection can be adjustable.
Technical Specifications
| TYPE | DDC | |
| Poles | 2p | 4p |
| Rated Voltage (V) | 230V | 440V |
| Rated Current (A) |
5~15A(5.10.15A) 15~45A(15.30.45A) |
10~30A(10.15.20.25.30A) 30~60A(30.45.60A) |
| Leakage operating current(mA) | 300mA | 500mA |
| Leakage non-operating current(mA) | 150mA | 250 |
| Standard | NFC61450,NFC62411 |
Electrical Circuit Breaker EDF Baco (500 mA Selective 4P 10/30 A) edf 69-30-066
Outshell and installation dimensions
Electrical Circuit Breaker EDF Baco (500 mA Selective 4P 10/30 A) edf 69-30-066
DDC BACO Adjustable circuit breaker.pdf
A: Yes, OEM/ODM packs are welcome. We are professional on OEM/ODM work.
A: Yes. We think that samples are very important for bulk orders. We can send samples.
A: Sure, we offer 1 or 2 years warranty for our products. That depends on different products.
